Filling and cleaning are done in only one single chamber-Through Holes and Blind Holes on both sides in one step
Included with the machine are:
- User controlled paste pressure for the filling process
- Filling of blind and through holes possible
- Full air-conditioned filling chamber
- Uses our patented filling head design
- Unique quick exchange system for very fast filling head change
- User-friendly programming with programmable parameters for all plugging parameters
- Real time paste level and consumption
- The machine is designed as a single chamber for vertical operation in order to save valuable floor space
- Less handling as squeegees for cleaning cycle are included in the same chamber
- De-Taping clamp included
- Machine fully made in stainless steel
| Parameters | Values |
|---|---|
| Panel thickness | 0.4 - 15.0 mm (0.016” – 0.59”) |
| Min. Hole size | 0.1 mm (0.004") |
| Max. Hole size | AR 1:1 (but not more than 2 mm) |
| Apsect Ratio | Max. Aspect ratio 40:1 |
